Melting Pot 7 Litres NL 4009 X / 010
-
Warranty 1 year
-
Free 14-Day returns
Description
Compound Melting
Designed for melting capping compounds, paraffin, and similar materials, compound melting pots feature an adjustable thermostat to deliver close temperature control automatically.
Specification
Overview
| Weight | 4 kg |
|---|---|
| Dimensions | 28 × 28 × 35 cm |
| Brand |
Nl Test |
| Model |
NL 4009 X / 010 |
| Capacity |
7 Litres |
|---|---|
| Temperature range |
50°C to 260°C |
| Voltage Supply |
220 – 240 V AC, 50 – 60 Hz, 1 ph |
| Rated Power |
1500 W |
