Eco Smartz Motorized Marshall Stability Compression 50kN NL 2010 X / 006
Newly invented bench mounting type machine, with rigid and compact design compare with previous model. By using DC motorised drive system to achieve more reliable and high accuracy result.
-
Warranty 1 year
-
Free 14-Day returns
Description
Standard: ASTM D1559, D5581, AASTHO T245, EN 12697-34, BS 598:107
Stability Compression
Newly invented bench mounting type machine, with rigid and compact design compare with previous model. By using DC motorised drive system to achieve more reliable and high accuracy result.
Specification
Overview
| Weight | 118 kg |
|---|---|
| Dimensions | 67 × 54.5 × 140 cm |
| Brand |
Nl Test |
| Model number |
NL 2010 X / 006 |
| Capacity |
50kN |
|---|---|
| Max Vertical Clearance (mm) |
730 mm |
| Max Horizontal Clearance (mm) |
270 mm |
| Testing Speed |
50.8 mm / min |
| Plunger Travel |
60 mm |
| Voltage Supply |
220 – 240 V AC, 50 – 60 Hz, 1 ph |
