Air Entrainment Meter B Type Complete with Carrying Case
- 7 litre capacity
- Shock-proof pressure gauge mounting
- Lightweight aluminum construction
- Heavy-duty plastic carrying case for easy transport to site
Downloads:
-
Warranty 1 year
-
Free 14-Day returns
Description
The proper control of entrained air in concrete is recognized as one of the most important functions in modern concrete manufacture. For the concrete engineer, the ELE Precision Air Entrainment Meter offers an instrument for the testing and designing of concrete mixes.
The instrument is designed so that the operating parts form an integral unit. The container is rigid, thus providing an accurate device for the performance of unit weight testing. For convenience, the tare weight in grams is stamped on the bottom. When used with the nomograph supplied within the operating instructions, the air meter provides quick and easy particle density and percent of free moisture in aggregate determinations.
Complies with EN 12350-7 (BS 1881-106), ASTM C231/C231M, AASHTO T152.
Specification
Overview
| Weight | 8 kg |
|---|---|
| Brand |
ELE International |
| Model |
34-3265 |
| Dimensions dia x height (inch) |
9.75 x 13.25 |
|---|---|
| ASTM C231 |
Yes |
| AASHTO T152 |
Yes |
| Readings |
Up to 22% entrained air |
| Accuracy |
0.25% full scale |
| Aggregate Size |
2" (50.8 mm) maximum |
| Container |
With tare weight stamped on bottom; 2-piece clamping device for positive seal. |
| Water |
4 oz required |
| Initial Pressure |
Approx. 10 strokes needed |
| Pressure Gauge |
In shock-proof mounting |
| Tamping Rod |
Aluminium; 24" (610 mm) long |
